Technical Data<\/h2>\n<\/div>\n

\n

\n

Model<\/div>\n

BL-WG-2030S<\/div>\n<\/div>\n

\n

Machine Type<\/div>\n

Grid Machine<\/div>\n<\/div>\n

\n

Applicable Wire Dia.<\/div>\n

W-shaped: Φ2.0mm \/ Plastic wrapped: Φ3.0mm<\/div>\n<\/div>\n

\n

No. of Control Axis<\/div>\n

28-34 Axis<\/div>\n<\/div>\n

\n

Weaving Station<\/div>\n

10 Axis<\/div>\n<\/div>\n

\n

W Forming Station<\/div>\n

2-4 Axis<\/div>\n<\/div>\n

\n

Plastic Wrapped Station<\/div>\n

12 Axis<\/div>\n<\/div>\n

\n

Total Power<\/div>\n

30KW<\/div>\n<\/div>\n

\n

Stabilized Power (Ref)<\/div>\n

40KW<\/div>\n<\/div>\n

\n

Pneumatic System<\/div>\n

0.5-0.6MPa<\/div>\n<\/div>\n

\n

Input Power<\/div>\n

380V\/50Hz\/3Ph<\/div>\n<\/div>\n

\n

Weight<\/div>\n

6000KG<\/div>\n<\/div>\n

\n

Machine Size(L×W×H)<\/div>\n

11500×4500×2400mm<\/div>\n<\/div>\n<\/div>\n<\/div>\n<\/div>\n

\n

\n

\n

Auxiliary Equipment Info<\/h2>\n<\/div>\n

\n

\n

Automatic Feeder Load<\/div>\n

200KG<\/div>\n<\/div>\n

\n

Feeder Tray Diameter<\/div>\n

Φ1800mm<\/div>\n<\/div>\n

\n

Feeder Input Power<\/div>\n

1.5KW<\/div>\n<\/div>\n

\n

Feeder Size(L×W×H)<\/div>\n

2200×2200×1500mm<\/div>\n<\/div>\n

\n

Grid Collecting Device<\/div>\n

Automatic Conveyor (Optional)<\/div>\n<\/div>\n

\n

Control System<\/div>\n

PLC + Touch Screen<\/div>\n<\/div>\n

\n

Protection Level<\/div>\n

IP54<\/div>\n<\/div>\n

\n

Operating Temperature<\/div>\n

-5\u2103~40\u2103<\/div>\n<\/div>\n

\n

Core Function<\/div>\n

Feeding→Forming→Cutting→Collecting<\/div>\n<\/div>\n<\/div>\n<\/div>\n<\/div>\n<\/div>\n<\/div>","diy_video":{"link":"https:\/\/v7-upload.digoodcms.com\/website_218\/2026-04-22\/69e83b3a7cc43-Seat%20Frame%20Wire%20Forming%20Machine%20BL-WG-2030S.mp4","image":"https:\/\/v7-upload.digoodcms.com\/website_218\/2026-04-23\/69e989ec62f67-jimeng-2026-02-24-6810-\u4fdd\u7559\u56fe\u7247\u4e2d\u7684\u8bbe\u5907\u4e3b\u4f53\uff0c\u6e05\u7406\u80cc\u666f\u4e2d\u7684\u73af\u5883\u5e72\u6270\u548c\u73bb\u7483\u53cd\u5149\uff0c\u66ff\u6362\u4e3a\u5e72\u51c0\u7684\u6d45\u7070\u8272\u6e10\u53d8\u80cc\u666f....png","title":"BL-WG-2030S","description":"BL-WG-2030S: Seat frame wire forming machine (grid machine), W-shaped steel wire 2.0mm \/ plastic wrapped steel wire 3.0mm, 30KW total power, 6000KG weight."},"diy_application":[{"pic":"https:\/\/v7-upload.digoodcms.com\/website_218\/2026-04-24\/69eac86f99300-split-image-4.jpg","desc":"Automotive","title":"Automotive seat serpentine spring frame"},{"pic":"https:\/\/v7-upload.digoodcms.com\/website_218\/2026-04-24\/69eac87640eef-split-image-1.jpg","desc":"Automotive","title":"Two-tone car seat spring assembly"},{"pic":"https:\/\/v7-upload.digoodcms.com\/website_218\/2026-04-24\/69eac87ca1c56-split-image-2.jpg","desc":"Automotive","title":"Seat serpentine springs with mounting hooks"},{"pic":"https:\/\/v7-upload.digoodcms.com\/website_218\/2026-04-24\/69eac8813c9d3-split-image-3.jpg","desc":"Automotive","title":"Seat backrest wave-shaped spring support"}],"diy_faq":null,"category_info":{"id":27,"guid":"HYoYHkEWNMI4m3f0kbSCo","language":"en","name":"Automotive Wire Mesh Forming Machine","label":"Automotive Wire Mesh Forming Machine","value":27,"defer":false,"collapsed":false},"updated_at_label":"07\/15 14:39"}]">Máquina de formado de malla de alambre automotriz
